Low Voltage Transformer Double Layer Foil Winding Machine

Low Voltage Foil Winding Machine is suitable for voltage under 1KV. The machine can lap winding and duplex winding for 2 layers of copper or aluminum foil. All the production parameters are set on the Human-Computer Interface and the machine works in fully automatic.

Main Machine Components

1.VF controlling stepless speed foil winding unit

2.Main machine frame with foil pressing, insulation edge cutting, photoelectric correction, conductor traction

3.Foil decoiler, 2 sets

4.Burr removing device & foil clean device, 2 sets

5.Feeder: 2 sets

6.Winder: 1 set

7.Paper Insulation decoiler, 2 sets

8.Automatic shearing device, 2 sets

9.Automatic TIG welding apparatus with welding machine, 1 set

10.Pneumatic positioning end insulation filling system, 2 sets

11.PLC controlling and touch screen operation system
